ON Semiconductor CAT24C08C5ATR EEPROM

The ON Semiconductor CAT24C08C5ATR is a high-performance, 8-Kb Serial Electrically Erasable Programmable Read-Only Memory (EEPROM) device, which offers a robust storage solution for complex electronic systems. This EEPROM is part of the CAT24Cxx series and is designed to provide non-volatile memory storage, making it ideal for a wide range of applications such as in consumer electronics, automotive systems, industrial controls, and smart devices.

Constructed with an advanced CMOS technology, the CAT24C08C5ATR ensures low power consumption, which is critical for battery-operated devices. The device operates over a wide voltage range of 1.7V to 5.5V, providing flexibility for use in systems with different power requirements. With a temperature range of -40°C to +85°C, it is guaranteed to perform reliably under extreme conditions, making it suitable for various harsh environments.

This EEPROM features an I²C-compatible (2-wire) serial interface, which facilitates easy integration into most microcontroller-based systems. The CAT24C08C5ATR supports a maximum clock frequency of 400 kHz (I²C Fast-mode), enabling quick data transfer rates that are essential for high-speed applications.

The memory is organized as 1024 x 8 bits (8 Kbits) and allows byte-wise or page-wise writing, which is up to 16 bytes per page. This flexibility in writing granularity helps optimize memory operations and reduces overall write cycle times. The device also includes a hardware write protection pin, which can be used to prevent unintended writes, thus enhancing data security.

ON Semiconductor has packaged the CAT24C08C5ATR in a space-saving 8-lead TSSOP package, making it a compact choice for designs where board space is at a premium. The EEPROM is also RoHS-compliant, ensuring that it meets current environmental standards for electronic components.

Overall, the CAT24C08C5ATR from ON Semiconductor is a reliable and efficient solution for applications requiring non-volatile memory storage. Its robust feature set and compact form factor make it an excellent choice for designers looking to enhance their systems with a durable and energy-efficient memory component.
