Introducing the MBRP20030CTL Schottky Rectifier from ON Semiconductor

The MBRP20030CTL is a state-of-the-art Schottky Barrier Rectifier designed by the renowned manufacturer ON Semiconductor, known for its high efficiency and reliability in power management solutions. This device is tailored for applications requiring low voltage drop and high-frequency operation. It is a perfect fit for switch-mode power supplies, converters, free-wheeling diodes, and reverse battery protection.

Key Features

• High Surge Capacity: The MBRP20030CTL can withstand high surge currents, making it suitable for applications that experience short bursts of high current.
• Low Forward Voltage Drop: Its low forward voltage drop ensures high efficiency, which is critical for energy-sensitive designs.
• High Junction Temperature: With a maximum junction temperature of 150°C, this device can operate reliably in high-temperature environments.
• Dual Diode Configuration: The center-tap dual diode configuration allows for flexibility in designs, enabling the use of the device in a full-wave configuration.

Specifications

Parameter Value Package / Case TO-247-3 Product Category Schottky Diodes & Rectifiers IF(AV) 2 x 10 A VRRM 30 V VF 0.55 V at 10 A IR 500 μA at 30 V Operating Temperature Range -65°C to +150°C

The MBRP20030CTL is encapsulated in a robust TO-247-3 package, which not only offers excellent power dissipation but also ensures mechanical ruggedness for various industrial applications. This component is RoHS compliant, highlighting ON Semiconductor's commitment to environmental sustainability.

Whether you're designing power supplies for consumer electronics, industrial systems, or automotive applications, the MBRP20030CTL from ON Semiconductor provides the performance and durability required for efficient and reliable operation. Trust this Schottky Rectifier to deliver top-notch performance where it matters most.
