ON Semiconductor MC100EPT21DR2G: Differential LVPECL to LVTTL Translator

The MC100EPT21DR2G is a high-performance integrated circuit designed by ON Semiconductor, tailored for applications that require translation from differential Low Voltage Positive Emitter Coupled Logic (LVPECL) levels to Low Voltage Transistor-Transistor Logic (LVTTL) levels. This device is an ideal choice for interfacing between systems operating at different voltage standards, ensuring signal integrity and compatibility across diverse platforms.

Key Features

• Signal Translation: Converts differential LVPECL input levels to LVTTL output levels, facilitating communication between devices operating at these distinct voltage standards.
• High Speed: With a typical propagation delay of only 2.5 ns, the MC100EPT21DR2G ensures rapid signal translation, making it suitable for high-speed data processing and communication applications.
• Dual Supply Operation: This translator operates with a 3.3 V supply for LVTTL and a 3.3 V or 5 V supply for LVPECL, offering flexibility in system design and power management.
• Temperature Range: The device is designed to operate over the industrial temperature range of -40°C to +85°C, ensuring reliable performance in a wide range of environments.
• Package: Housed in an 8-pin SOIC package, the MC100EPT21DR2G is compact and suitable for space-constrained applications.

Applications

The MC100EPT21DR2G is versatile and can be used in various applications, including but not limited to:

• Telecommunications
• Data Communication Equipment
• Networking Hardware
• Computer Peripherals
• Signal Conversion in Mixed Voltage Systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality and reliability, and the MC100EPT21DR2G is no exception. It is manufactured with high-quality materials and subjected to rigorous testing to ensure it meets industry standards for performance and durability. Users can trust in the robustness of this product for their critical applications.

Whether you are upgrading existing systems or designing new ones, the MC100EPT21DR2G from ON Semiconductor provides a reliable and efficient solution for LVPECL to LVTTL signal translation, ensuring seamless integration and communication between different electronic components.
