ON Semiconductor MC74HC1G32DFT1G Product Overview

The ON Semiconductor MC74HC1G32DFT1G is a high-performance, single-gate logic OR gate integrated circuit that belongs to the 74HC family. This product is designed to operate with a power supply voltage ranging from 2V to 6V, making it an extremely versatile component for a wide array of electronic applications. Its low power consumption and high noise immunity are characteristic of CMOS technology, which is ideal for battery-operated and portable devices.

Key Features

• Logic Type: 2-Input OR Gate
• Supply Voltage Range: 2.0V to 6.0V
• Output Current: High: -0.5mA, Low: 0.5mA
• Operating Temperature Range: -55°C to +125°C
• Mounting Type: Surface Mount
• Package / Case: SC-70-5 (SOT-353)
• Propagation Delay Time: 8ns at 4.5V
• Logic Level - Low: 0.1V x Vcc (max)
• Logic Level - High: 0.9V x Vcc (min)

Applications

The MC74HC1G32DFT1G is engineered for multipurpose use in the electronics field. It is commonly found in logic systems requiring OR gate functions, including:

• Control systems
• Alarm systems
• Data processing
• Embedded systems
• Signal processing

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the MC74HC1G32DFT1G is no exception. This product is fabricated using robust silicon-gate CMOS technology, which ensures long-term reliability. It also features protection against excessive voltage with its integrated input protection diodes. The device is compliant with the JEDEC standard no. 7A requirements, ensuring compatibility with most CMOS, NMOS, and TTL logic levels.

Environmental Compliance

The MC74HC1G32DFT1G from ON Semiconductor is also environmentally friendly. It is compliant with RoHS (Restriction of Hazardous Substances) and is free from lead (Pb), ensuring that it meets global environmental standards and can be used in green products.
