ON Semiconductor MC7805CTG Voltage Regulator

The ON Semiconductor MC7805CTG is a robust linear voltage regulator designed to offer a fixed positive output voltage of 5V. This reliable component is a part of the MC7800 series, which is well-known for providing stable and consistent voltage regulation, making it an ideal choice for a wide range of electronic applications.

Key Features:

• Output Voltage: 5V fixed output with high accuracy.
• Output Current: Capable of delivering up to 1A of continuous current.
• Thermal Overload Protection: Ensures the device remains safe under excessive temperature conditions.
• Short Circuit Protection: Provides additional safety by preventing damage from output short circuits.
• No External Components Required: Internal compensation minimizes the need for external components.
• High Ripple Rejection: Offers excellent stability and noise immunity for sensitive circuits.
• Package: Available in a TO-220 package that is easy to integrate into various circuit designs.

Applications:

The MC7805CTG is versatile and can be implemented in numerous applications, including:

• Consumer Electronics
• Computer Systems
• Power Management Solutions
• Automotive Electronics
• Telecommunication Systems

Product Specifications:

Parameter Value Output Voltage (V<sub>OUT) 5V Output Current (I<sub>OUT) 1A Input Voltage (V<sub>IN) Up to 35V Package / Case TO-220-3 Operating Temperature -40°C to +125°C

Whether you're designing power supplies, building consumer electronics, or developing automotive systems, the ON Semiconductor MC7805CTG provides a dependable solution for your voltage regulation needs with its combination of performance, protection features, and ease of use.
