ON Semiconductor MJD31C1G NPN Power Transistor

The MJD31C1G from ON Semiconductor is a robust NPN bipolar power transistor designed for general-purpose amplifier and switching applications. This component is housed in a DPAK (TO-252) surface-mount package, which is well-suited for automated assembly processes and offers a compact footprint for space-constrained applications.

Key Features

• High Collector-Emitter Voltage: With a V<sub>CEO of 100V, the MJD31C1G can handle a wide range of voltages in electronic circuits, making it versatile for numerous applications.
• Collector Current: The device supports a continuous collector current (I<sub>C) of up to 3A, allowing it to drive moderate loads in power switching circuits.
• Power Dissipation: It has a power dissipation rating of 20W, providing a good balance between thermal performance and power handling capability.
• High DC Current Gain: With a h<sub>FE (DC current gain) range of 30 to 240, this transistor can amplify a small input current into a much larger output current, which is essential for driving loads or for signal amplification.
• Fast Switching Speeds: The device is designed to offer fast switching performance, which is critical for efficient operation in high-speed switching applications.
• Complementary PNP Type: The MJD31C1G has a complementary PNP partner, the MJD32C1G, allowing designers to implement push-pull configurations for more efficient power conversion.

Applications

The MJD31C1G is ideal for a variety of applications, including:

• Power regulators
• Motor controls
• Audio amplifiers
• Switching circuits
• Power management functions

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the MJD31C1G is no exception. It is manufactured to meet high standards for reliability and performance, making it a trusted choice for both commercial and industrial applications. Whether you are designing power supplies, motor controllers, or audio systems, the MJD31C1G offers a reliable and efficient solution for your NPN power transistor needs.
