ON Semiconductor NCP4687DH18T1G Voltage Regulator

The NCP4687DH18T1G is a high-performance, low-dropout linear voltage regulator designed and manufactured by ON Semiconductor, a leader in energy-efficient innovations. This compact and efficient component is ideal for a wide range of applications, including portable devices, where power efficiency and space constraints are critical considerations.

Key Features

• Output Voltage: The NCP4687DH18T1G provides a fixed output voltage of 1.8V, which is suitable for powering low-voltage digital circuits and microcontrollers.
• High Accuracy: This voltage regulator offers excellent load and line regulation, ensuring a stable output voltage even under varying input voltage and load conditions.
• Low Dropout: With a low dropout voltage, the NCP4687DH18T1G maintains regulation with minimal difference between the input and output voltages, making it efficient for battery-powered applications.
• Current Capacity: It is capable of supplying up to 150 mA of output current, catering to the needs of small to medium power requirements.
• Thermal Protection: The device includes thermal shutdown protection, which safeguards the regulator and the system from excessive temperature and potential damage.
• Small Footprint: Housed in a compact 5-pin TSOP-5 package, the NCP4687DH18T1G saves valuable board space and is suitable for space-constrained applications.

Applications

The NCP4687DH18T1G is versatile and can be used in various electronic devices, including:

• Mobile phones and PDAs
• Portable media players
• Wireless LAN devices
• GPS receivers
• Portable gaming consoles
• Digital cameras

With its high accuracy, low power consumption, and small size, the NCP4687DH18T1G from ON Semiconductor is an excellent choice for designers looking to optimize their power management solutions. Its robust protection features and stable performance under diverse conditions make it a reliable component for maintaining the integrity of electronic systems.
