The NL17SH32P5T5G from ON Semiconductor is a high-performance, single 2-input OR gate integrated circuit, designed to meet the needs of a wide range of digital applications. This small yet powerful device is a fundamental component in digital electronics, used in various systems where logic operations are essential.

Key Features

• Logic Type: 2-Input OR Gate
• Operating Voltage Range: 1.65V to 5.5V, accommodating a variety of logic level requirements and ensuring compatibility with both low-voltage and standard logic devices.
• High-Speed Operation: With a typical propagation delay of only 4.5ns at 5V, the NL17SH32P5T5G is designed for applications requiring fast switching and high-speed logic operations.
• Low Power Consumption: The device is optimized for low power consumption, making it ideal for battery-powered and power-sensitive applications.
• Output Drive Capability: Capable of driving up to 4mA at 5V, allowing it to interface with other logic devices, microcontrollers, and peripheral components with ease.
• Temperature Range: Operating temperature range from -55°C to +125°C, ensuring reliable performance across a wide range of environmental conditions.
• Mounting Type: Surface Mount, packaged in a compact SOT-953 format for space-saving PCB design.
• Lead-Free and RoHS Compliant: The device adheres to environmental regulations, minimizing the ecological impact and making it suitable for use in a variety of markets.

Applications

The versatility of the NL17SH32P5T5G allows it to be used in a multitude of applications, including but not limited to:

• Smartphones and portable electronics
• Computing and data storage systems
• Communication infrastructure
• Industrial control systems
• Consumer electronics

With its compact size, low power consumption, and high-speed operation, the NL17SH32P5T5G from ON Semiconductor is an essential building block for designers looking to create efficient and reliable digital systems.
