ON Semiconductor NSR20F40NXT5G Product Overview

The NSR20F40NXT5G is a state-of-the-art Schottky Barrier Diode designed by ON Semiconductor, renowned for its high efficiency and reliability. This diode is part of ON Semiconductor's extensive portfolio of power management and signal conditioning products, which are well-suited for a wide range of applications across various industries.

Key Features

• Low Forward Voltage Drop: The NSR20F40NXT5G boasts a low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
• High Surge Capability: This device is capable of handling high surge currents, making it ideal for applications that experience frequent power surges and spikes.
• Power Dissipation: With a power dissipation rating of 200 mW, this Schottky diode can manage moderate levels of power, suitable for a variety of electronic circuits.
• Low Power Loss and High Efficiency: The diode is optimized for low power loss, ensuring high efficiency in power conversion and management tasks.
• Compact Package: Enclosed in a small SOD-323 package, the NSR20F40NXT5G is perfect for space-constrained applications, without compromising on performance.

Applications

The NSR20F40NXT5G from ON Semiconductor is versatile and can be used across a broad spectrum of applications. Some of the typical applications include:

• Power Supply Rectification
• DC-DC Converters
• Freewheeling Diodes
• Reverse Voltage Protection
• Portable Devices
• LED Lighting

Technical Specifications

Parameter Value Package Type SOD-323 Repetitive Reverse Voltage V<sub>RRM 40V Average Rectified Forward Current I<sub>o 2A Non-Repetitive Peak Forward Surge Current I<sub>FSM 20A Power Dissipation P<sub>D 200mW

ON Semiconductor's NSR20F40NXT5G is designed for high-performance applications that require a compact footprint without sacrificing efficiency and reliability. Its robust construction and advanced semiconductor technology make it a top choice for engineers and designers looking for a dependable Schottky Barrier Diode.
