ON Semiconductor NUP1301: ESD Protection Diode

The ON Semiconductor NUP1301 is a cutting-edge ESD protection diode designed to safeguard high-speed data lines and I/O ports from electrostatic discharge (ESD), cable discharge events (CDE), and electrical fast transients (EFT). This versatile component is a perfect fit for applications that demand robust protection in a compact package.

Key Features:

• ESD Protection: The NUP1301 provides exceptional protection against ESD, withstanding ESD strikes up to ±20 kV in air and ±15 kV in contact discharge, as per the IEC 61000-4-2 standard.
• Low Capacitance: With its low loading capacitance of just 3 pF typical, the NUP1301 is ideal for protecting high-speed data lines without compromising signal integrity.
• Multi-Line Protection: The device can protect up to four data or I/O lines, offering a compact solution for multiple lines in a single package.
• Low Leakage Current: It features a low leakage current of less than 0.1 μA, ensuring minimal power loss when in standby mode.
• Fast Response Time: The diode's fast response time ensures quick activation upon detecting an ESD event, thus providing immediate protection for sensitive circuitry.

Applications:

The NUP1301 is designed for a broad range of applications, particularly where high-speed data integrity and protection are crucial. It is commonly used in:

• USB 1.1/2.0/3.0 Interfaces
• HDMI 1.3/1.4/2.0 Ports
• FireWire Ports
• SATA and eSATA Ports
• DisplayPort Interfaces
• Gigabit Ethernet Ports
• Mobile Handsets
• Notebook Computers
• Set-Top Boxes
• Digital Cameras and Video Equipment

Package and Quality:

The NUP1301 comes in a small SOT-23-6 package, making it suitable for space-constrained applications. It is RoHS compliant and backed by ON Semiconductor's commitment to high-quality standards, ensuring reliability and performance in your electronic designs.
