The EEE1AA100NR is an aluminum electrolytic capacitor manufactured by Panasonic. It is a radial leaded type capacitor suitable for various electronic applications, particularly where high capacitance and stable performance are required.

Applications

• Power Supplies: Used for filtering and smoothing DC voltage in power supplies.
• Audio Equipment: Employed in audio amplifiers and other audio circuits for decoupling and filtering.
• Consumer Electronics: Found in devices like TVs, DVD players, and set-top boxes for power filtering and regulation.
• Industrial Equipment: Utilized in control systems, power distribution units, and motor drives for stable operation.
• Lighting Systems: Used in lighting circuits for smoothing and stabilizing voltage.

Features

• Aluminum Electrolytic Construction: Offers a high capacitance-to-volume ratio.
• Radial Leaded: Allows for easy through-hole mounting on circuit boards.
• High Ripple Current Capability: Suitable for applications with high current fluctuations.
• Long Life: Provides extended operational lifespan, enhancing the reliability of the end product.
• RoHS Compliant: Complies with environmental regulations, minimizing hazardous substances.

Benefits

• Stable Performance: Delivers consistent capacitance over a range of temperatures and frequencies.
• Cost-Effective: Provides a balance of performance and affordability.
• Reliable Operation: Ensures long-term stability and dependable performance in various environments.
• Easy Installation: Simplifies the assembly process due to its radial leaded design.
• Wide Operating Temperature: Designed to operate reliably over a broad temperature range.

Additional Details

The EEE1AA100NR capacitor typically has a capacitance value of 10μF and a voltage rating of 10V. It is designed to operate within a specified temperature range, generally from -40°C to +85°C. The capacitor also offers low Equivalent Series Resistance (ESR), contributing to improved efficiency and reduced heat generation. It is frequently used in power supply circuits for filtering and smoothing, as well as in decoupling applications to reduce noise and voltage ripple. The specific dimensions, tolerance values, and other technical specifications can be found in the manufacturer's datasheet. This capacitor is a reliable and cost-effective choice for numerous electronic applications requiring stable and efficient performance.
