HE1AN-S-AC120V Panasonic – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

HE1AN-S-AC120V

Part No HE1AN-S-AC120V
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 30A 120V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Chassis Mount
Coil Voltage 120VAC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 30 A
Switching Voltage 277VAC, 30VDC - Max
Load - Max Switching 8310VA, 900W
Coil Current 22.1 mA
Coil Type Non Latching
Termination Style Screw Terminal
Must Operate Voltage 84 VAC
Must Release Voltage 18 VAC
Operate Time 30 ms
Release Time 30 ms
Temperature Range - Operating -50°C ~ 55°C
Contact Material Silver Tin Oxide (AgSnO)
Approval Agency CSA, VDE, UR
Relay Type General Purpose
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1549096-HE1AN-S-AC120V
Ultra Librarian 3D Model Ultra Librarian HE1AN-S-AC120V CAD Model
