MTM231232LBF Real Image MTM231232LBF real image3782
Same model may have multiple batches, images only for reference.
MTM231232LBF Real Image MTM231232LBF real image3782
MTM231232LBF Real Image MTM231232LBF real image3782
Same model may have multiple batches, images only for reference.

MTM231232LBF

Part No MTM231232LBF
Manufacturer Panasonic
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 3A
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Panasonic Electronic Components
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.3V @ 1mA
Max Input Capacitance 1000pF @ 10V
Maximum Gate-Source Voltage ±10V
Power Dissipation (Max) 500mW (Ta)
Maximum Rds On at Id,Vgs 55 mOhm @ 1A, 4V
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package SC-70-3 (SOT323)
Dimension SC-70, SOT-323
Win Source Part Number 024583-MTM231232LBF
Popularity Medium
Supply and Demand Status Balance
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MTM231232LBF CAD Model

Description

The Panasonic Electronic Components MOSFET is a high-performance semiconductor device that is designed for use in a wide range of applications.

  • Maximum Power Dissipation: 500mW
  • Ideal for: Power management circuits, voltage regulators, and other electronic devices
  • Polarity: P-Channel
  • Drain-Source Breakdown Voltage: 20V
  • Suitable for: Use in low-power applications
  • Maximum Rds On @ Id, Vgs: 55 mOhm @ 1A, 4V
  • Gate-Source Threshold Voltage: 1.3V @ 1mA
  • Packaging: SC-70-3 (SOT323)
  • Market Popularity: medium
