CSR8635B04-IQQF-R real image CSR8635B04-IQQF-R real image21559
Same model may have multiple batches, images only for reference.
CSR8635B04-IQQF-R real image CSR8635B04-IQQF-R real image21559
CSR8635B04-IQQF-R real image CSR8635B04-IQQF-R real image21559
Same model may have multiple batches, images only for reference.

CSR8635B04-IQQF-R

Part No CSR8635B04-IQQF-R
Manufacturer Qualcomm
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU BLUETOOTH 68VFQFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Transceiver ICs
Mfr Qualcomm
Package Tape & Reel
Product Status Not For New Designs
Programmable Not Verified
Type TxRx + MCU
RF Family/Standard Bluetooth
Protocol Bluetooth v4.1
Power - Output 8dBm
Sensitivity -91dBm
Memory Size 56KB RAM
Serial Interfaces I²C, I²S, SPI, PCM, UART, USB
GPIO 22
Mounting Type Surface Mount
Package / Case 68-VFQFN Exposed Pad
Supplier Device Package 68-QFN (8x8)
Base Product Number CSR8635
Standard Package 2,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 5A992C
HTSUS 8542.39.0001
Win Source Part Number 771909-CSR8635B04-IQQF-R
Ultra Librarian 3D Model Ultra Librarian CSR8635B04-IQQF-R CAD Model

Description

The 771909-CSR8635B04-IQQF-R is a RF transceiver IC manufactured by Qualcomm.

  • Category: RF and Wireless - RF Transceiver ICs
  • Packaging: Tape & Reel
  • Standard Package: 2,000 pcs
  • Protocol: Bluetooth v4.1
  • Memory Size: 56KB RAM
  • Type: TxRx + MCU
  • Power Output: 8dBm
  • Sensitivity: -91dBm
  • Serial Interfaces: I²C, I²S, SPI, PCM, UART, USB
  • GPIO Count: 22
  • Mounting Type: Surface Mount
  • Package/Case: 68-VFQFN Exposed Pad
  • Supplier Device Package: 68-QFN (8x8)
  • ECCN: 5A992C
  • MSL Level: 3 (168 hours)
  • HTSUS Code: 8542.39.0001
  • Recommendation: Not recommended for new designs
