Same model may have multiple batches, images only for reference.

NP100P04PDG-E1-AY

Name: NP100P04PDG-E1-AY
Brand: Renesas Electronics America
SKU: 790767
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	NP100P04PDG-E1-AY
Manufacturer	Renesas Electronics America
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 40V 100A TO-263 / Trans MOSFET P-CH 40V 100A Automotive 3-Pin(2+Tab) D2PAK T/R
Datasheet	NP100P04PDG-E1-AY Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Renesas Electronics America
Packaging	Reel package
Channel Type Type	P
Technology	MOSFET
Drain Source Voltage	40V
Current - Continuous Drain (Id) @ 25°C	100A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Vgs(th) (Maximum) @ Id	2.5V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs	320nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	15100pF @ 10V
Vgs (Maximum)	±20V
Power Dissipation (Maximum)	1.8W (Ta), 200W (Tc)
Rds On (Maximum) @ Id, Vgs	3.5 mOhm @ 50A, 10V
Operating Temperature Range	175°C (TJ)
Mounting	SMD
Manufacturer Package	TO-263
Package	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	790767-NP100P04PDG-E1-AY
Popularity	Medium
Supply and Demand Status	Limited
Family Name	NP100P04PDG
Introduction Date	May 07, 2007
ECCN	EAR99
Country of Origin	Japan, Malaysia
Estimated EOL Date	2022
Ultra Librarian 3D Model	Ultra Librarian NP100P04PDG-E1-AY CAD Model

Alternative Products

Description

The Renesas Electronics America NP100P04PDG-E1-AY is a MOSFET technology-based semiconductor device.

Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Continuous Drain Current: 100A (Tc) @ 25°C
Drain-Source Voltage: 40V
Gate-Source Voltage: ±20V
Power Dissipation: 1.8W (Ta), 200W (Tc)
Input Capacitance (Ciss): 15100pF @ 10V
Gate Charge (Qg): 320nC @ 10V
