NP75P04YLG-E1-AY

Name: NP75P04YLG-E1-AY
Brand: Renesas Electronics America
SKU: 258934
Availability: InStock
Rating: 4.93 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NP75P04YLG-E1-AY
Manufacturer	Renesas Electronics America
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 40V 75A 8HSON
Datasheet	NP75P04YLG-E1-AY Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Renesas Electronics America
Packaging	Reel - TR
Status	Obsolete(EOL)
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	40V
Continuous Drain Current at 25°C	75A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	5V, 10V
Gate-Source Threshold Voltage	2.5V @ 250μA
Max Gate Charge	140nC @ 10V
Max Input Capacitance	4800pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	1W (Ta), 138W (Tc)
Maximum Rds On at Id,Vgs	9.7 mOhm @ 37.5A, 10V
Temperature Range - Operating	175°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-HSON
Dimension	8-SMD, Flat Lead Exposed Pad
Win Source Part Number	125991-NP75P04YLG-E1-AY
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian NP75P04YLG-E1-AY CAD Model

Alternative Products

Description

The Renesas NP75P04YLG-E1-AY is a medium-popularity electronic component that is suitable for various applications.

Supply and Demand: balanced
Manufacturer: Renesas Electronics America
Win Source Part Number: 125991
Technology: MOSFET
Polarity: P-Channel
Power Dissipation: 1W (Ta), 138W (Tc)
Drain-Source Breakdown Voltage: 40V
Status: obsolete (EOL)
Temperature Range: 175°C (TJ)
Maximum Gate-Source Voltage: ±20V
Maximum Rds On at Id,Vgs: 9.7 mOhm @ 37.5A, 10V
