The 74HC123A from Rochester Electronics is a high-speed silicon-gate CMOS monostable multivibrator with Schmitt-trigger inputs. This device offers stable operation over a wide voltage and temperature range, making it suitable for various timing and pulse-generation applications.

Applications:

• Precision timing circuits
• Pulse delay generation
• Pulse width discrimination
• Missing pulse detection
• Time delay generation
• Astable multivibrator

Features:

• High-speed operation: tpd = 11 ns (typ.) at VCC = 5V
• Wide operating voltage range: 2V to 6V
• Low power dissipation: ICC = 4 μA (max.) at TA = 25°C
• High noise immunity: VNIH = VNIL = 30% VCC (min.)
• Schmitt-trigger inputs for improved noise immunity
• Output drive capability: 10 LSTTL loads
• Pin and function compatible with the 74LS123A

Benefits:

• Precise timing: Offers accurate and stable timing pulses for various applications.
• Noise immunity: Schmitt-trigger inputs minimize the impact of noisy input signals, ensuring reliable operation.
• Low power consumption: Minimizes power requirements, suitable for battery-powered devices.
• Wide operating voltage: Adaptable to different power supply conditions.
• Easy to use: Pin-compatible with industry-standard 74LS123A devices.

Additional Details:

The 74HC123A integrates two independent monostable multivibrators, each triggered by either a positive-going or negative-going transition. The device features a clear input that, when low, resets the timing cycle. The output pulse width is determined by the external timing components RX and CX. The device is available in various packages, including DIP and SOIC. The recommended operating temperature range is -40°C to +85°C.

Note: Always refer to the manufacturer's datasheet for the most accurate and up-to-date specifications and application information.
