Same model may have multiple batches, images only for reference.

RJK005N03T146

Name: RJK005N03T146
Brand: Rohm Semiconductor
SKU: 295124
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	RJK005N03T146
Manufacturer	Rohm Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 500MA SOT-346
Datasheet	RJK005N03T146 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Rohm Semiconductor
Packaging	Reel - TR
Status	Not For New Designs
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	500mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Gate-Source Threshold Voltage	1.5V @ 1mA
Max Gate Charge	4nC @ 4V
Max Input Capacitance	60pF @ 10V
Maximum Gate-Source Voltage	±12V
Power Dissipation (Max)	200mW (Ta)
Maximum Rds On at Id,Vgs	580 mOhm @ 500mA, 4.5V
Temperature Range - Operating	150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SMT3
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	027417-RJK005N03T146
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian RJK005N03T146 CAD Model

Alternative Products

Description

The Rohm Semiconductor 027417-RJK005N03T146 is a MOSFET transistor that is perfect for use in various electronic devices.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 500mA (Ta)
