The SEAF-20-05.0-S-04-2-A-K-TR is a high-density, high-speed connector from Samtec's SEARAY™ family. This connector is designed for board-to-board applications requiring reliable signal transmission in compact electronic devices. The 'SEAF' designates a SEARAY™ female connector. It offers a robust solution for demanding interconnect applications.

Applications:

• High-speed data transmission
• Networking equipment
• Telecommunications systems
• Medical devices
• Industrial automation

Features:

• High-density contact array: Allows for a large number of signals in a small footprint.
• High-speed performance: Optimized for signal integrity at high data rates.
• Surface mount termination: Facilitates automated assembly processes.
• Robust mating interface: Ensures reliable connection under vibration and shock.
• RoHS compliant: Environmentally friendly, adhering to Restriction of Hazardous Substances directives.

Benefits:

• Increased board density: Maximizes the number of connections in a limited space.
• Improved signal integrity: Minimizes signal distortion and ensures reliable data transmission.
• Simplified assembly: SMT design allows for efficient and cost-effective manufacturing.
• Enhanced system reliability: Robust design ensures stable and consistent performance.
• Environmentally compliant: Meets environmental regulations, promoting sustainable practices.

Technical Specifications:

Based on the part number, we can deduce some specifications. 'SEAF' signifies a SEARAY™ female connector. '20' likely relates to the number of rows. '05.0' probably indicates a stack height of 5.0mm. 'S' suggests surface mount. '04' indicates 4 positions per row, '2' specifies 2 rows. 'A' denotes an alignment pin, 'K' is the option code, and 'TR' denotes tape and reel packaging for automated assembly. Detailed electrical specifications like impedance, voltage rating, and current rating are available from the Samtec datasheet for this specific part number.
