The Samtec Inc. Tiger Eye™ SFMC is a connector used for board to board or cable connections.

• Connector Type: receptacle-type connector.
• Positions: 74 positions.
• Pitch: 0.050" (1.27mm).
• Contact Type: female socket contact type.
• Positions Loaded: all positions.
• Rows: two rows.
• Row Spacing: 0.050" (1.27mm).
• Termination: solder termination.
• Fastening Type: push-pull fastening type.
• Mounting: through-hole.
• Contact Finish: gold contact finish with a thickness of 3.00µin (0.076µm) for mating and a tin contact finish for post.
• Current Rating: 2.9A per contact.
• Operating Temperature: -55°C ~ 125°C.
• Package: packaged in a tube.
• Standard Package: 1.
