ZM5202AH-CME3R Real Image
Same model may have multiple batches, images only for reference.

ZM5202AH-CME3R

Part No ZM5202AH-CME3R
Manufacturer Sigma Designs Inc.
Catalog RF Transceiver Modules
Description RF TXRX MODULE ISM / Fully Integrated Z-Wave Wireless Module
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Sigma Designs Inc.
Series Z-Wave
Packaging Reel package
RF Family/Standard General ISM
Protocol Z-Wave
Frequency 921MHz
Data Rate 100Kbps
Power - Output 4dBm
Sensitivity -103dBm
Serial Interfaces SPI, UART, USB
Memory Size 128kB Flash, 16kB SRAM
Operating Supply Voltage 2.3 V ~ 3.6 V
Current - Receiving 32mA
Current - Transmitting 41mA
Mounting SMD
Package Module
Win Source Part Number 800384-ZM5202AH-CME3R
Popularity Medium
Supply and Demand Status Limited
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian ZM5202AH-CME3R CAD Model

Description

The Sigma Designs Inc. Z-Wave module, with Win Source part number 800384-ZM5202AH-CME3R, is a General ISM RF family/standard module that operates in the 921MHz frequency range.

  • Frequency: 921MHz
  • Data Rate: 100Kbps
  • Sensitivity: -103dBm
  • Power Output: 4dBm
  • Current (Receiving): 32mA
  • Current (Transmitting): 41mA
  • Memory Size: 128kB Flash, 16kB SRAM
  • Serial Interfaces: SPI, UART, and USB
  • Mounting Type: SMD
  • Operating Supply Voltage: 2.3V to 3.6V
  • Protocol: Z-Wave
  • Estimated Availability: 2027
  • Supply and Demand Status: Limited
