AAT3238IGU-1.5-T1 Advanced Analog Technology
Same model may have multiple batches, images only for reference.

AAT3238IGU-1.5-T1

Part No AAT3238IGU-1.5-T1
Manufacturer Skyworks Solutions Inc.
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR 1.5V 300MA SOT23-6
Datasheet
AAT3238IGU-1.5-T1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr Skyworks Solutions Inc.
Series microPOWER™
Package Tape & Reel
Product Status Obsolete
Output Configuration Positive
Output Type Fixed
Number of Regulators 1
Voltage - Input (Max) 5.5V
Voltage - Output (Min/Fixed) 1.5V
Voltage Dropout (Max) 0.6V @ 300mA
Current - Output 300mA
Current - Quiescent (Iq) 125 µA
PSRR 67dB ~ 45dB (1kHz ~ 1MHz)
Control Features Enable
Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case SOT-23-6
Supplier Device Package SOT-23-6
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 744165-AAT3238IGU-1.5-T1
Ultra Librarian 3D Model Ultra Librarian AAT3238IGU-1.5-T1 CAD Model

Description

The 744165-AAT3238IGU-1.5-T1 is a linear voltage regulator from the microPOWER™ series by Skyworks Solutions Inc. It is designed for power management applications in electronic circuits.

  • Current Output: 300mA
  • Output Type: Fixed
  • Input Voltage: Up to 5.5V
  • Output Voltage: 1.5V
  • Mounting: Surface Mountable
  • Package: SOT-23-6
  • Enable Control: Yes
  • Protection: Over Temperature, Short Circuit
  • Operating Temperature Range: -40°C to 85°C
  • PSRR: 67dB to 45dB
  • Status: Obsolete
  • Demand: 30% in open market
