2N4235 Boca Semiconductor Corporation
Same model may have multiple batches, images only for reference.

2N4235

Part No 2N4235
Manufacturer Solid State Inc.
Catalog Transistors (BJT) - Single
Description TRANS PNP 60V 1A TO39
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single Bipolar Transistors
Mfr Solid State Inc.
Package Bulk
Product Status Active
Transistor Type PNP
Current - Collector (Ic) (Max) 1 A
Voltage - Collector Emitter Breakdown (Max) 60 V
Vce Saturation (Max) @ Ib, Ic 600mV @ 125mA, 1A
Current - Collector Cutoff (Max) 1mA
DC Current Gain (hFE) (Min) @ Ic, Vce 40 @ 100mA, 1V
Power - Max 1 W
Frequency - Transition 3MHz
Temperature Range - Operating -65°C ~ 200°C (TJ)
Mounting Type Through Hole
Package / Case TO-205AD, TO-39-3 Metal Can
Supplier Device Package TO-39
Standard Package 10 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 541163-2N4235
Ultra Librarian 3D Model Ultra Librarian 2N4235 CAD Model

Description

The 2N4235 is a PNP bipolar transistor designed for general-purpose amplification applications. Solid State Inc.'s 2N4235 is a PNP bipolar transistor designed for general-purpose amplification applications.

  • Maximum Power Rating: 1 W
  • Voltage Breakdown: 60 V
  • Maximum Collector Current: 1 A
  • Vce Saturation: 600mV @ 125mA and 1A
  • DC Current Gain (hFE): 40 @ 100mA and 1V
  • Mounting Type: Through-hole
  • Package: TO-205AD and TO-39-3 Metal Can
  • Operating Temperature Range: -65°C to 200°C
  • Market Status: Active
