The BAT41ZFILM is a high-performance Schottky diode from the renowned semiconductor manufacturer STMicroelectronics. This diode is designed to offer fast switching capabilities, low forward voltage drop, and high efficiency, making it an ideal choice for a wide range of applications.

Key Features

• Low Forward Voltage Drop: The BAT41ZFILM boasts a very low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
• Fast Switching Speed: With its fast switching action, this diode is well-suited for high-frequency applications, contributing to better performance in circuits where rapid switching is required.
• Surface-Mount Package: It comes in a compact DO-213AB surface-mount package, which allows for efficient use of PCB space and is suitable for automated assembly processes.
• High Reliability: Built with STMicroelectronics' quality and reliability, the BAT41ZFILM is designed to withstand harsh conditions and provide stable performance over its lifespan.
• Lead-Free and RoHS Compliant: The diode is environmentally friendly, complying with current RoHS directives, making it suitable for use in green and sustainable technology solutions.

Applications

The BAT41ZFILM is versatile and can be used in a variety of electronic circuits, including:

• Power supply units
• DC-DC converters
• Reverse polarity protection
• Switching power supplies
• Adapters
• Battery chargers
• Automotive applications
• Portable devices and high-frequency systems

Technical Specifications

Parameter Value Repetitive Peak Reverse Voltage (V<sub>RRM) 100 V Average Forward Current (I<sub>F(AV)) 200 mA Non-Repetitive Peak Forward Surge Current (I<sub>FSM) 1 A Operating Junction Temperature (T<sub>j) -40°C to +125°C Storage Temperature Range (T<sub>stg) -65°C to +150°C

With its robust design and efficient performance, the STMicroelectronics BAT41ZFILM Schottky diode is a reliable component for engineers and designers looking to enhance the performance of their electronic designs.
