STMicroelectronics LMV324LIDT Low-Power Quad Operational Amplifier

The LMV324LIDT from STMicroelectronics is a high-performance, low-power quad operational amplifier that is designed to offer a perfect balance between low voltage operation and low power consumption, making it an ideal choice for battery-powered applications and portable devices. This operational amplifier comes in a compact 14-pin SOIC package, providing a space-efficient solution for a wide range of electronic circuits.

With a supply voltage range of 2.7V to 5.5V, the LMV324LIDT is optimized for low voltage applications. It boasts a low supply current of 220 µA, which is ideal for extending battery life in portable devices. Despite its low power consumption, this op-amp does not compromise on performance. It features a high gain bandwidth product of 1 MHz and a slew rate of 1 V/µs, ensuring that it can handle a variety of signal processing tasks with ease.

The input common-mode voltage range includes ground, which allows for direct sensing near ground. This feature is particularly useful in single-supply operations. Furthermore, the LMV324LIDT offers rail-to-rail output swing, which provides the maximum possible dynamic range at the output. This is especially beneficial when operating at low supply voltages.

Another notable feature of the LMV324LIDT is its low input offset voltage of 7 mV, which minimizes error and improves accuracy in signal amplification and conditioning applications. The device also includes an internal frequency compensation which ensures stability without the need for any external components.

STMicroelectronics has designed the LMV324LIDT with robustness in mind. It can operate over a wide temperature range of -40°C to +125°C, making it suitable for industrial and automotive applications that require reliable performance under harsh conditions.

Whether it's for sensor interfaces, battery-supplied and portable applications, or any general-purpose analog signal processing, the LMV324LIDT operational amplifier is a versatile and efficient solution that delivers consistent performance while maintaining low power consumption.
