Product Overview: M24256-BWMN6P by STMicroelectronics

The M24256-BWMN6P is a 256-Kbit I²C-compatible EEPROM (Electrically Erasable Programmable Read-Only Memory) produced by the renowned semiconductor manufacturer, STMicroelectronics. This high-performance memory chip is designed to provide flexible data storage solutions for a wide range of electronic applications, from automotive to industrial control systems.

Key Features:

• Memory Size: The device offers a substantial storage capacity of 256 Kbits, organized as 32,768 × 8 bits, which is ideal for applications requiring the storage of configuration parameters, serial numbers, or calibration data.
• Interface: It operates via an I²C serial bus interface, supporting both the standard (up to 100 kHz) and fast (up to 400 kHz) modes, making it easily integrable with a wide range of microcontrollers and processors.
• Supply Voltage: The M24256-BWMN6P operates within a supply voltage range of 2.5V to 5.5V, making it versatile for use in both low and standard voltage applications.
• Write Cycle Time: It boasts a fast write cycle time, with a byte write within 5 ms, ensuring quick data storage and minimal delay in system operations.
• Data Retention: Users can expect a data retention period of more than 40 years, providing a reliable solution for long-term data storage needs.
• Write Endurance: The EEPROM is engineered for high write endurance, capable of 1 million write cycles per byte, ensuring a long operational lifespan for applications that require frequent data updates.
• Package: This particular model, M24256-BWMN6P, is available in a narrow 8-pin SOIC package, suitable for PCB mounting and ideal for space-constrained applications.

Applications:

The M24256-BWMN6P is a versatile memory component that can be used in various applications, including:

• Automotive systems for storing user settings and error logs
• Industrial and medical equipment for calibration and configuration data
• Consumer electronics, such as smart appliances and personal gadgets
• Communication systems and data storage modules

With its robust design and reliable performance, the M24256-BWMN6P from STMicroelectronics stands out as a superior choice for designers and engineers looking to incorporate a dependable EEPROM into their electronic systems.
