STB11NM60FDT4 - High-Performance N-Channel MOSFET by STMicroelectronics

The STB11NM60FDT4 is a state-of-the-art N-Channel MOSFET brought to you by STMicroelectronics, a leader in semiconductor solutions. This power MOSFET is designed to deliver high-efficiency power conversion in various applications, including switch-mode power supplies, motor control, and power management tasks. It is well-suited for high-performance applications that require low on-resistance, high switching speed, and superior thermal performance.

Key Features

• Low On-Resistance (R<sub>DS(on)): The STB11NM60FDT4 boasts an exceptionally low drain-source on-resistance, resulting in reduced conduction losses and improved overall efficiency in power conversion circuits.
• High Switching Speed: With its fast switching capabilities, this MOSFET is ideal for high-frequency power switching applications, ensuring minimal switching losses and better performance in power regulation tasks.
• Improved Gate Charge: The optimized gate charge of the STB11NM60FDT4 allows for reduced switching times, which contributes to the efficiency of the device in high-speed switch-mode applications.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, ensuring reliability and robustness in applications where the device may be subjected to high-energy pulses.
• High dv/dt Capability: The MOSFET is designed to withstand high voltage changes per unit time (dv/dt), making it suitable for applications with rapid voltage transitions.

Applications

• Switch-mode power supplies (SMPS)
• DC/DC converters
• Power inverters
• Motor control systems
• Power management circuits

The STB11NM60FDT4 is housed in a TO-220 package, which is widely used in commercial and industrial applications due to its robustness and excellent thermal properties. The device is also RoHS compliant and compatible with lead-free soldering processes, reflecting STMicroelectronics' commitment to environmental sustainability.

With its combination of high efficiency, fast switching, and rugged design, the STB11NM60FDT4 is a perfect choice for designers looking to optimize their power conversion systems. Its performance and reliability are in line with the quality standards expected from STMicroelectronics, a company with a reputation for excellence in the field of power semiconductor devices.
