STB16NF06LT4

Part No STB16NF06LT4
Manufacturer STMicroelectronics
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 16A D2PAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 16A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
Gate-Source Threshold Voltage 1V @ 250ÎĽA (Min)
Max Gate Charge 10nC @ 4.5V
Max Input Capacitance 345pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 45W (Tc)
Maximum Rds On at Id,Vgs 90 mOhm @ 8A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 099137-STB16NF06LT4
Family Name STB16NF06
Introduction Date February 01, 2002
ECCN EAR99
Country of Origin United States of America
Halogen Free Compliant
Estimated EOL Date 2026
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Alternative Parts
(Cross-Reference)
NDB4060L;  IRFZ24NSTRLPBF;  NTB18N06G;

Description

STB16NF06LT4 - N-Channel 60V 16A Power MOSFET by STMicroelectronics

The STB16NF06LT4 is a high-performance N-Channel Power MOSFET designed and manufactured by STMicroelectronics, a global semiconductor leader known for its state-of-the-art electronic components. This MOSFET is part of ST's STripFET™ II series, which is renowned for its low on-resistance and low gate charge, making it an excellent choice for a wide range of power management applications.

With a drain-source voltage (VDS) of 60V and a continuous drain current (ID) of 16A, the STB16NF06LT4 is capable of handling significant power levels. The device is optimized for high switching speeds, which is essential for efficient power conversion in modern electronic circuits. The low threshold voltage ensures that the MOSFET can be driven at lower gate voltages, thus reducing the power required to switch the device on and off.

The STB16NF06LT4 comes in a D2PAK package, which is ideal for surface-mount technology (SMT) and provides excellent thermal performance. This package is widely used in industry and is known for its robustness, making it suitable for both commercial and industrial applications. The device also features an extremely low intrinsic capacitance, which further enhances its switching performance.

Key features of the STB16NF06LT4 include:

  • Low threshold voltage for improved efficiency
  • Exceptionally low on-resistance (RDS(on))
  • High current capability
  • Fast switching speed
  • 100% avalanche tested for reliability
  • Low gate charge and input capacitance

Applications for the STB16NF06LT4 are diverse and include:

  • Switching regulators
  • DC-DC converters
  • Motor control
  • Power management in computing and telecom systems
  • Automotive applications

The STB16NF06LT4 is a testament to STMicroelectronics' commitment to providing advanced power management solutions that meet the needs of the evolving electronics industry. Its combination of high performance, efficiency, and reliability makes it an excellent choice for designers looking to optimize their power circuitry.
