The STB200NF04T4 is a state-of-the-art N-Channel MOSFET brought to you by STMicroelectronics, a leader in semiconductor solutions. This high-performance MOSFET is designed to meet the needs of a wide range of applications, offering both efficiency and reliability.

Key Features

• Low On-Resistance: The STB200NF04T4 boasts an exceptionally low on-resistance (R<sub>DS(on)), which translates into reduced conduction losses and improved overall efficiency in electronic circuits.
• High Current Capability: This MOSFET can handle a continuous drain current (I<sub>D), making it suitable for high-power applications that require robust current handling capabilities.
• High Switching Speed: The fast switching speed of the STB200NF04T4 minimizes switching losses and is ideal for high-frequency power switching applications.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche performance, ensuring reliability and robustness in harsh conditions.
• Low Gate Charge: The device features a low gate charge (Q<sub>g), which reduces the power required to drive the MOSFET, thereby saving energy and extending battery life in portable applications.

Applications

The versatility of the STB200NF04T4 allows it to be used in a variety of applications, including but not limited to:

• Switch Mode Power Supplies (SMPS)
• Power Management Systems
• DC-DC Converters
• Motor Control Circuits
• Automotive and Industrial Applications

Product Specifications

The STB200NF04T4 operates in a wide range of temperatures, ensuring performance in diverse environments. It is encapsulated in a D2PAK package, which is known for its durability and thermal performance, making it an excellent choice for thermally demanding scenarios. With its combination of low on-resistance, high current capability, and fast switching speeds, the STB200NF04T4 stands out as a high-efficiency component in the field of power electronics.

For engineers and designers looking for a robust and efficient N-Channel MOSFET, the STB200NF04T4 from STMicroelectronics offers a compelling solution that can enhance the performance and reliability of their electronic designs.
