Introducing the STB46N30M5 N-channel MOSFET by STMicroelectronics

The STB46N30M5 is a state-of-the-art N-channel Power MOSFET designed and manufactured by the renowned semiconductor company, STMicroelectronics. This high-performance MOSFET is part of ST's MDmesh™ M5 series, which is engineered to provide exceptional efficiency, particularly in high-switching applications.

Key Features

• Low On-Resistance (R<sub>DS(on)): The STB46N30M5 boasts an impressively low on-resistance, which translates to reduced conduction losses and improved overall efficiency in power conversion applications.
• High Voltage Capability: With a drain-source voltage (V<sub>DS) of 300V, this MOSFET can handle high voltage operations, making it suitable for a variety of demanding applications.
• High Current Rating: The device supports a continuous drain current (I<sub>D) of 46A, ensuring robust performance for high-power tasks.
• Reduced Gate Charge (Q<sub>g): An optimized gate charge allows for faster switching speeds, which is critical in applications such as switching power supplies and motor control.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, guaranteeing reliability and durability even under stressful conditions.

Applications

The versatility of the STB46N30M5 MOSFET makes it an ideal choice for a wide range of applications, including:

• Switching power supplies
• DC/DC converters
• Motor control
• Power management solutions
• LED lighting solutions

Package and Quality

The STB46N30M5 comes in a D2PAK package, known for its compact footprint and excellent thermal performance. The device is RoHS compliant and adheres to STMicroelectronics' commitment to environmental sustainability.

In conclusion, the STB46N30M5 from STMicroelectronics is a robust and reliable N-channel MOSFET that offers a combination of high efficiency, fast switching, and ruggedness. Its technical excellence makes it a go-to component for engineers looking to optimize their power management systems.
