STB55NF06T4 - N-Channel MOSFET by STMicroelectronics

The STB55NF06T4 is a high-performance N-Channel MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This power MOSFET is designed to deliver efficient power conversion in a variety of applications, from power supplies to motor controls. With its robust design and advanced manufacturing technology, the STB55NF06T4 is an ideal choice for high-efficiency power management tasks.

Key Features

• High Current Capability: The STB55NF06T4 is capable of handling continuous drain currents up to 55 A, making it suitable for high-power applications.
• Low On-Resistance: With an RDS(on) value of just 14 mΩ (max), this MOSFET ensures minimal power loss and improved efficiency during operation.
• High Switching Speed: The fast switching performance of the STB55NF06T4 reduces switching losses and improves the overall efficiency of power conversion circuits.
• 100% Avalanche Tested: Reliability is a key aspect of the STB55NF06T4, which is guaranteed through rigorous avalanche testing.
• Application Versatility: Suitable for a wide range of applications including DC-DC converters, motor drivers, and power management systems.

Electrical Characteristics

• Drain-source Voltage (V<sub>DS): 60V
• Gate-source Voltage (V<sub>GS): ±20V
• Continuous Drain Current (I<sub>D): 55A
• Power Dissipation (P<sub>D): 110W
• Operating Temperature Range: -55°C to 175°C

Package and Quality

The STB55NF06T4 is available in a D2PAK package, known for its durability and thermal efficiency. The device's package is designed to optimize the thermal resistance and footprint size, making it a compact and reliable solution for modern electronic designs. STMicroelectronics ensures that the STB55NF06T4 meets the highest quality standards, with rigorous testing and quality control measures in place.

Overall, the STB55NF06T4 N-Channel MOSFET from STMicroelectronics stands out for its efficiency, reliability, and versatility, making it an excellent choice for designers looking to optimize their power conversion systems.
