STB80NF55-06T - N-Channel MOSFET by STMicroelectronics

The STB80NF55-06T is a robust N-channel Power MOSFET designed and manufactured by the renowned semiconductor company, STMicroelectronics. This high-performance transistor is a part of ST's STripFET™ II series, which is known for its exceptional quality and efficiency. The device is tailored for applications that demand high current and fast switching performance, making it an ideal choice for power supply units, motor controls, and high-efficiency converters.

Key Features

• Low On-Resistance: The STB80NF55-06T boasts an ultra-low on-resistance (R<sub>DS(on)), which significantly reduces conduction losses and improves overall efficiency in high-current applications.
• High Current Capability: With a continuous drain current (I<sub>D) of up to 80A, this MOSFET can handle substantial power levels, making it suitable for demanding tasks.
• High Switching Speed: The device's fast switching speed ensures minimal switching losses and is particularly advantageous in applications where high-frequency operation is essential.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, guaranteeing reliability and robustness under stressful conditions.
• Low Gate Charge: The MOSFET's low gate charge (Q<sub>g) contributes to its fast switching characteristics and reduces the power required to drive the gate, thus saving energy.

Applications

The versatility of the STB80NF55-06T allows it to be utilized in a wide range of applications. It is particularly well-suited for:

• Switch Mode Power Supplies (SMPS)
• DC-to-AC Inverters
• DC-to-DC Converters
• Motor Drives and Controllers
• Automotive Applications
• LED Lighting Solutions

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STB80NF55-06T is designed with this commitment in mind, ensuring a reliable performance in a wide temperature range and under various operating conditions. Its robustness and longevity make it a preferred choice for engineers and professionals seeking components that offer both performance and durability.

With its combination of efficiency, power handling, and reliability, the STB80NF55-06T N-channel MOSFET from STMicroelectronics stands out as a superior component for power management and conversion applications.
