STGP19NC60S STMicroelectronics – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Product Status Obsolete
Voltage - Collector Emitter Breakdown (Max) 600 V
Current - Collector (Ic) (Max) 40 A
Current - Collector Pulsed (Icm) 80 A
Vce(on) (Max) @ Vge, Ic 1.9V @ 15V, 12A
Power - Max 130 W
Switching Energy 135µJ (on), 815µJ (off)
Input Type Standard
Gate Charge 54.5 nC
Td (on/off) @ 25°C 17.5ns/175ns
Test Condition 480V, 12A, 10Ohm, 15V
Mounting Type Through Hole
Case / Package TO-220-3
Supplier Device Package TO-220
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1495092-STGP19NC60S
Ultra Librarian 3D Model Ultra Librarian STGP19NC60S CAD Model
