STM32F745VEH6 Microcontroller Overview

The STM32F745VEH6 is a high-performance, advanced line microcontroller from STMicroelectronics that is part of their STM32F7 series. This microcontroller is based on the ARM Cortex-M7 processor with a Double Precision Floating Point Unit (FPU), which is designed to offer the best performance to cost ratio for a wide range of applications.

With a maximum CPU frequency of 216 MHz, the STM32F745VEH6 provides the computational power needed for complex and demanding applications. It features a 1MB of Flash memory and 320KB of SRAM, which are essential for storing and running applications with extensive code and data sets.

Key Features

• Core: ARM® Cortex®-M7 with FPU and Adaptive real-time accelerator (ART Accelerator™)
• Operating Frequency: Up to 216 MHz
• Flash Memory: 1MB
• SRAM: 320KB
• Supply Voltage: 1.7 V to 3.6 V
• Operating Temperature Range: -40°C to +105°C
• Communication Interfaces: I2C, SPI, UART, USART, USB OTG, CAN, SAI, SDMMC, and Ethernet
• Advanced peripherals: Graphics accelerator, Digital camera interface, and Cryptographic acceleration

Connectivity and Graphics

The STM32F745VEH6 is equipped with a range of connectivity options, including I2C, SPI, UART, USART, and CAN interfaces for communication with other devices. It also features USB OTG for device/host functionality and an Ethernet MAC for network connectivity. Additionally, the microcontroller supports advanced graphics with its Chrom-ART Accelerator™, which enhances graphic performance, and a digital camera interface, enabling the integration of imaging modules.

Security and Encryption

Security features are paramount in today's connected world, and the STM32F745VEH6 integrates hardware cryptographic acceleration to ensure data protection and secure transactions. It provides support for algorithms like AES and HASH (MD5, SHA-1), enhancing the security of your applications.

Power Efficiency

Designed with power efficiency in mind, the STM32F745VEH6 offers multiple power modes, including a flexible low-power mode and a VBAT mode for RTC and backup registers. This ensures that applications can maintain efficiency even in power-sensitive scenarios.

Overall, the STM32F745VEH6 is a robust and versatile microcontroller that is ideal for applications requiring high computational power, graphics, and connectivity, while still emphasizing power efficiency and security.
