STW40N60M2 - Power MOSFET by STMicroelectronics

The STW40N60M2 is a high-performance N-channel 600V, 40A MDmesh™ M2 Power MOSFET designed and manufactured by STMicroelectronics, a global semiconductor leader. This power MOSFET is part of the MDmesh M2 series that features state-of-the-art technology optimized for high-efficiency applications in power conversion and switching.

Key Features

• Voltage Rating: The STW40N60M2 is rated for a drain-source voltage (V<sub>DS) of 600V, making it suitable for high-voltage applications.
• Current Handling: It can handle continuous drain current (I<sub>D) up to 40A, allowing it to drive substantial loads.
• R<sub>DS(on): The device boasts a low on-resistance (R<sub>DS(on)) which enhances its efficiency by minimizing conduction losses.
• Fast Switching: Fast switching speeds are achieved thanks to the device's optimized gate charge (Q<sub>g), reducing switching losses.
• Temperature Performance: With an operating junction temperature range of -55°C to 150°C, the STW40N60M2 is designed for robust performance in a wide range of environmental conditions.
• 100% Avalanche Tested: Ensuring reliability in rugged applications, each device is subjected to an avalanche test guaranteeing its ruggedness.

Applications

The STW40N60M2 is ideal for a variety of applications that require high efficiency and power density. These include:

• Switch Mode Power Supplies (SMPS)
• LED Lighting
• Welding Equipment
• Solar Inverters
• Uninterruptible Power Supplies (UPS)
• High-Performance Drives

Quality and Support

STMicroelectronics is committed to delivering high-quality products. The STW40N60M2 is supported by comprehensive technical documentation, including datasheets, application notes, and design tools. Customers can also benefit from ST's extensive support network for design-in assistance and technical support.

Environmental Compliance

The STW40N60M2 is compliant with RoHS and other environmental standards, reflecting STMicroelectronics' dedication to environmental sustainability and reducing the ecological impact of its products.
