STW45NM60 - High Performance Power MOSFET by STMicroelectronics

The STW45NM60 is a state-of-the-art power MOSFET designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This device is part of the MDmesh™ series, which utilizes an innovative vertical process technology to create MOSFETs with extremely low on-resistance and high blocking voltage capability.

Key Features

• High Voltage Capability: The STW45NM60 operates at a drain-source voltage (V_DS) of 600V, making it suitable for high voltage applications.
• Low On-Resistance: With an on-resistance (R_DS(on)) as low as 0.045 Ω, this MOSFET ensures high efficiency and minimizes power losses during operation.
• High Current Rating: The device can handle continuous drain currents (I_D) up to 45A, making it capable of driving high current loads.
• Fast Switching Speed: The STW45NM60 is designed for fast switching applications, reducing switching losses and improving performance in high-frequency circuits.

Applications

The STW45NM60 is ideal for a wide range of applications, including:

• Switch Mode Power Supplies (SMPS)
• High Efficiency DC-DC Converters
• Motor Control Systems
• Power Factor Correction Circuits
• Lighting Applications
• Welding Equipment

Package and Quality

This MOSFET is offered in a TO-247 package, which provides excellent thermal performance and is suitable for high power density applications. STMicroelectronics ensures high reliability and performance by adhering to stringent quality standards, making the STW45NM60 a reliable choice for critical and demanding applications.

Design Support

STMicroelectronics provides comprehensive technical support, including datasheets, application notes, and design tools to assist engineers in integrating the STW45NM60 into their designs. With its outstanding features and support, the STW45NM60 is an excellent choice for designers looking to improve efficiency and power density in their high voltage power conversion applications.
