AZ23C5V6 Real Image AZ23C5V6 real image17544 AZ23C5V6 Real Image
Same model may have multiple batches, images only for reference.
AZ23C5V6 Real Image AZ23C5V6 real image17544 AZ23C5V6 Real Image
AZ23C5V6 Real Image AZ23C5V6 real image17544 AZ23C5V6 Real Image
Same model may have multiple batches, images only for reference.

AZ23C5V6

Part No AZ23C5V6
Manufacturer Taiwan Semiconductor
Catalog Diodes - Zener - Arrays
Description SOT-23, 300MW, 5%, SMALL SIGNAL
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Zener Diode Arrays
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Configuration 1 Pair Common Anode
Voltage - Zener (Nom) (Vz) 5.6 V
Tolerance ±5%
Power - Max 300 mW
Impedance (Max) (Zzt) 40 Ohms
Current - Reverse Leakage @ Vr 100 nA @ 1 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23
Base Product Number AZ23C
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 567559-AZ23C5V6
Ultra Librarian 3D Model Ultra Librarian AZ23C5V6 CAD Model

Description

The 567559-AZ23C5V6 is a zener diode array designed for various electronic applications.

  • Nominal voltage: 5.6 V
  • Tolerance: ±5%
  • Configuration: common anode pair
  • Mounting: surface mountable
  • Maximum power dissipation: 300 mW
  • Maximum reverse leakage current: 100 nA @ 1 V
  • Series: AZ23C series from Taiwan Semiconductor
  • Status: active and available
  • Packaging: tape and reel
