PC29.07.0100A

Part No PC29.07.0100A
Manufacturer Taoglas Limited
Catalog RF Antennas
Description RF ANT 850MHZ/900MHZ FLAT PATCH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard Cellular
Frequency Group UHF (300MHz ~ 1GHz), UHF (1GHz ~ 2GHz)
Frequency (Center/Band) 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz
Antenna Type Flat Patch
Number of Bands 5
VSWR 1.58, 1.78, 1.51, 1.38, 1.37
Return Loss -13dB, -11dB, -14dB, -16dB, -16dB
Gain 0.01dBi, 1.2dBi, 2.66dBi, 1.25dBi, 1.43dBi
Termination U.FL (UMCC), I-PEX MHF1
Mounting Type Adhesive
Height (Max) 0.031" (0.80mm)
Applications CDMA, GSM, UMTS
Package Bag
Supply and Demand Status Shortage
Win Source Part Number 1510908-PC29.07.0100A
Ultra Librarian 3D Model Ultra Librarian PC29.07.0100A CAD Model
