ECO2017SEO-D03V014

Part No ECO2017SEO-D03V014
Manufacturer TDK Corporation
Catalog Switching Converter, SMPS Transformers
Description XFMR FLYBACK AC/DC CONV 555UH TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type For AC/DC Converters
Applications Flyback Converters
Voltage - Primary 85 ~ 264V
Voltage - Auxiliary 12V @ 1A
Voltage - Isolation 3000Vrms
Inductance @ Frequency 555µH @ 100kHz
Temperature Range - Operating -30°C ~ 120°C
Mounting Type Through Hole
Size / Dimension 0.768" L x 0.886" W (19.50mm x 22.50mm)
Height - Seated (Max) 0.945" (24.00mm)
Footprint 0.768" L x 0.886" W (19.50mm x 22.50mm)
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1511106-ECO2017SEO-D03V014
Ultra Librarian 3D Model Ultra Librarian ECO2017SEO-D03V014 CAD Model

Description
