NLC453232T-220K-PF Real Image NLC453232T-220K-PF label picture
Same model may have multiple batches, images only for reference.
NLC453232T-220K-PF Real Image NLC453232T-220K-PF label picture
NLC453232T-220K-PF Real Image NLC453232T-220K-PF label picture
Same model may have multiple batches, images only for reference.

NLC453232T-220K-PF

Part No NLC453232T-220K-PF
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 22UH 370MA 900 MOHM
Datasheet
NLC453232T-220K-PF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging Reel - TR
Status Active
Type Wirewound
Material - Core Ferrite
Inductance 22μH
Tolerance ±10%
Current Rating 370mA
DC Resistance (DCR) 900 mOhm Max
Q @ Freq 10 @ 2.52MHz
Frequency - Self Resonant 18MHz
Temperature Range - Operating -40°C to 105°C
Frequency - Test 2.52MHz
Mounting SMD (SMT)
Case / Package 1812
Height - Seated (Max) 0.134" (3.40mm)
Win Source Part Number 025498-NLC453232T-220K-PF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian NLC453232T-220K-PF CAD Model

Description

This electronic component, manufactured by TDK Corporation, is a wirewound inductor with a current rating of 370mA and an inductance of 22μH.

  • Current Rating: 370mA
  • Inductance: 22μH
  • Core Material: Ferrite
  • Q @ Freq: 10 @ 2.52MHz
  • Frequency Self-Resonant: 18MHz
  • Frequency Test: 2.52MHz
  • DC Resistance (DCR): 900 mOhm Max
  • Mounting Technology: SMD (SMT)
  • Tolerance: ±10%
  • Height when seated: 0.134" (3.40mm)
  • Packaging: Reel-TR
  • Category: Inductors, coils, chokes
  • Popularity: High
  • Supply and Demand: Balanced
