PH50S24-15 Real Image
Same model may have multiple batches, images only for reference.

PH50S24-15

Part No PH50S24-15
Manufacturer TDK-Lambda Americas Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description CONVERT DC-DC 15V 50W 3.4A / Module DC-DC 24VIN 1-OUT 15V 3.4A 50W 6-Pin
Datasheet
PH50S24-15 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer TDK-Lambda Americas Inc.
Series PH-S
Packaging Bulk
Part Status Obsolete(EOL)
Type Isolated Module
Number of Outputs 1
Input Voltage MIN 18V
Voltage Input MAX 36V
Voltage - Output 1 15V
Current - Output (Maximum) 3.4A
Power (Watts) 50W
Voltage - Isolation 3kV (3000V)
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, OVP
Operating Temperature Range -20°C ~ 85°C
Mounting Style Through Hole
Package Module
Dimension 3.85" L x 1.61" W x 0.50" H (86.0mm x 41.0mm x 12.7mm)
Win Source Part Number 791755-PH50S24-15
Popularity Medium
Supply and Demand Status Limited
Family Name PH50S24-15
Introduction Date December 01, 2005
ECCN EAR99
Country of Origin Japan, Malaysia
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian PH50S24-15 CAD Model

Description

The TDK-Lambda Americas Inc. PH-S series isolated module is a high-quality product that offers a reliable and secure connection for your electronic devices. The product is supplied in bulk packaging and is suitable for use in ITE (Commercial) applications.

  • Output Voltage: 15V
  • Output Current: 3.4A
  • Packaging: Bulk
  • Applications: ITE (Commercial)
  • Supply and Demand Status: Limited
  • Product Category: Power Supplies - Board Mount
