PH50S2412 Real Image
Same model may have multiple batches, images only for reference.

PH50S2412

Part No PH50S2412
Manufacturer TDK-Lambda Americas Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description CONVERTER DC/DC 12V 50W 6-PIN / Module DC-DC 24VIN 1-OUT 12V 4.2A 50W 14-Pin
Datasheet
PH50S2412 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer TDK-Lambda Americas Inc.
Series PH-S
Packaging Bulk
Part Status Obsolete(EOL)
Type Isolated Module
Number of Outputs 1
Input Voltage MIN 18V
Voltage Input MAX 36V
Voltage - Output 1 12V
Current - Output (Maximum) 4.2A
Power (Watts) 50W
Voltage - Isolation 3kV (3000V)
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, OVP
Operating Temperature Range -20°C ~ 85°C
Mounting Style Through Hole
Package Module
Dimension 3.85" L x 1.61" W x 0.50" H (86.0mm x 41.0mm x 12.7mm)
Win Source Part Number 791754-PH50S2412
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1
Family Name PH50S24-12
Introduction Date October 10, 2008
ECCN EAR99
Country of Origin Japan, Malaysia
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian PH50S2412 CAD Model

Description

The TDK-Lambda Americas Inc. PH50S2412 is an isolated module type power supply with a power output of 50W. It has a voltage isolation of 3kV (3000V) and an input voltage range of 18V to 36V.

  • Power: 50W
  • Voltage Isolation: 3kV (3000V)
  • Input Voltage: 18V to 36V
  • Temperature Range: -20°C to 85°C
  • Features: Remote On/Off, OCP, OTP, OVP
  • Output Voltage: 12V
  • Output Current: 4.2A
  • Package Dimensions: 3.85" L x 1.61" W x 0.50" H (86.0mm x 41.0mm x 12.7mm)
  • Mounting Style: Through Hole
  • Applications: ITE (Commercial)
