Same model may have multiple batches, images only for reference.

PV3-48-3.3

Name: PV3-48-3.3
Brand: TDK-Lambda Americas Inc.
SKU: 1103629
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	PV3-48-3.3
Manufacturer	TDK-Lambda Americas Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 3.3V 2W / Isolated Module DC DC Converter 1 Output 3.3V 600mA 36V - 72V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	TDK-Lambda Americas Inc
Series	PV (3W)
Package	Bulk
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	36V
Voltage - Input (Max)	72V
Voltage - Output 1	3.3V
Current - Output (Max)	600mA
Power (Watts)	2 W
Voltage - Isolation	500 V
Applications	ITE (Commercial)
Features	OCP
Temperature Range - Operating	-20°C ~ 70°C
Efficiency	77%
Mounting Type	Through Hole
Package / Case	10-SIP Module, 9 Leads
Dimension	1.30" L x 0.33" W x 0.71" H (33.0mm x 8.5mm x 18.0mm)
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	PV3483.3,PV3-48-3.3,PV3483.3-ND,285-PV3-48-3.3
Standard Package	1
Win Source Part Number	1103629-PV3-48-3.3
Ultra Librarian 3D Model	Ultra Librarian PV3-48-3.3 CAD Model

Alternative Products

Description

The PV (3W) isolated module DC-DC converter is a reliable and efficient power supply solution for ITE (Commercial) applications.

Voltage Isolation: 500V
Maximum Output Current: 600mA
Output Voltage: 3.3V
OCP: Features OCP
Efficiency: 77%
Temperature Range: -20°C to 70°C
Mounting Type: Through-hole
Package/Case: 10-SIP module with 9 leads, measuring 1.30" L x 0.33" W x 0.71" H (33.0mm x 8.5mm x 18.0mm)
Alternative Parts: PV1R5-48-5, PG02S4803A, NDL4809SC, RS-4805S, IZ4803SA, and IU4809SAPV3483.3
Manufacturer: TDK-Lambda Americas Inc
ECCN: EAR99.40.9580
