Same model may have multiple batches, images only for reference.
OMIH-SH-112L,394 TE Connectivity
Same model may have multiple batches, images only for reference.

OMIH-SH-112L,394

Part No OMIH-SH-112L,394
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPDT 16A 12V
Datasheet
OMIH-SH-112L,394 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Tube/Rail
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 45mA
Coil Voltage 12VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 16A
Switching Voltage 250VAC, 30VDC - Max
Turn On Voltage (Max) 9 VDC
Turn Off Voltage (Min) 0.6 VDC
Operate Time 20ms
Release Time 8ms
Features Sealed - Fully
Mounting Through Hole
Termination Style PC Pin
Coil Power 540 mW
Coil Resistance 270 Ohms
Temperature Range - Operating -30°C to 70°C
Win Source Part Number 132452-OMIH-SH-112L,394
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian OMIH-SH-112L,394 CAD Model

Description

This relay component is manufactured by TE Connectivity Potter & Brumfield Relays and has a medium popularity in the market.

  • Contact Form: SPDT (1 Form C)
  • Mounting: Through-hole
  • Coil Resistance: 270 Ohms
  • Coil Current: 45mA
  • Relay Type: General purpose
  • Coil Voltage: 12VDC
  • Contact Rating (Current): 16A
  • Switching Voltage: 250VAC, 30VDC - Max
  • Turn On Voltage (Max): 9 VDC
  • Turn Off Voltage (Min): 0.6 VDC
  • Release Time: 8ms
  • Coil Power: 540 mW
  • Temperature Range: -30°C to 70°C
