Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Teccor Electronics
Win Source Part Number 1241164-Q2015LT
Manufacturer Homepage www.littelfuse.com/
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Lighting, HVAC, Industrial, Consumer Electronics
Ultra Librarian 3D Model Ultra Librarian Q2015LT CAD Model

Description

The Q2015LT is a 20 Amp Alternistor Triac from Teccor Electronics, designed for high-performance full-wave AC control applications. This device is specifically engineered to switch inductive or resistive loads in AC power control circuits.

Applications:

  • AC solid-state switches.
  • Light dimmers.
  • Motor speed controls.
  • Heating controls.
  • Solenoid control.

Features:

  • High blocking voltage capability: Ensures reliable operation in high voltage applications.
  • High surge current capability: Robust design to withstand transient current surges.
  • Glass passivated junction: Provides excellent voltage blocking capability and long-term reliability.
  • Sensitive gate triggering: Enables easy triggering with low gate current.
  • Isolated mounting tab: Simplifies thermal management and electrical isolation.

Benefits:

  • Improved system reliability: The robust design and high surge current capability ensure reliable operation, reducing the risk of system failures.
  • Simplified circuit design: The sensitive gate triggering feature simplifies the design of triggering circuits.
  • Efficient AC power control: Provides efficient and precise control of AC power to the load.
  • Enhanced thermal performance: The isolated mounting tab allows for efficient heat dissipation.

Additional Details:

The Q2015LT features a repetitive peak off-state voltage (VDRM) and repetitive peak reverse voltage (VRRM) that meets industry standards for AC power control. The on-state RMS current (IT(RMS)) is rated for 20 Amps, making it suitable for a wide range of applications. The gate trigger current (IGT) is specified to ensure reliable triggering with various control circuits. The device is available in a TO-220 isolated package, providing convenient mounting and thermal management. It is designed to operate within a specified temperature range, ensuring stable performance in diverse operating conditions. This triac offers high performance and reliability for demanding AC power control applications.
