BQ24230RGTT Texas Instruments BQ24230RGTT real image2654
Same model may have multiple batches, images only for reference.
BQ24230RGTT Texas Instruments BQ24230RGTT real image2654
BQ24230RGTT Texas Instruments BQ24230RGTT real image2654
Same model may have multiple batches, images only for reference.

BQ24230RGTT

Part No BQ24230RGTT
Manufacturer Texas Instruments
Catalog PMIC - Battery Chargers
Description IC LI+ CHARGER PWR MGMT 16QFN
Datasheet
BQ24230RGTT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Battery Chemistry Lithium-Ion
Number of Cells 1
Current - Charging Constant - Programmable
Programmable Features Timer
Fault Protection Over Temperature, Over Voltage, Reverse Current, Short Circuit
Charge Current - Max 500mA
Battery Pack Voltage 4.2V
Maximum Supply Voltage 6.4V
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 16-QFN (3x3)
Win Source Part Number 011940-BQ24230RGTT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BQ24230RGTT CAD Model

Description

BQ24230RGTT Battery Charger IC

The BQ24230RGTT offers the same reliable power management capabilities as the BQ24230RGTR, with a slight variation in its form factor, supporting a range of mobile applications.

  • Applications: Mobile devices, GPS units, digital cameras

Features and Benefits:

  • Flexible support for various input power sources including USB
  • Advanced power management in a compact form factor
  • Seamless integration with existing designs
  • Built-in safety features for protected charging

This charger IC is designed to maintain the battery’s longevity and performance, making it a preferred choice for designers seeking reliability and efficiency.
