CD4070BM96

Part No CD4070BM96
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE XOR 4CH 2-INP 14-SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type XOR (Exclusive OR)
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 3 V to 18 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 3.4mA, 3.4mA
Logic Level - Low 1.5 V to 4 V
Logic Level - High 3.5 V to 11 V
Max Propagation Delay @ V, Max CL 100ns @ 15V, 50pF
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 012865-CD4070BM96
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name CD4070
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian CD4070BM96 CAD Model

Description

CD4070BM96

The CD4070BM96 offers high-performance four XOR gate logic operations. This IC is designed to work seamlessly in a multitude of digital circuit applications, ensuring efficiency and reliability.

Features and Benefits

  • Efficient power usage, essential for minimizing energy consumption.
  • Operates over a broad supply voltage range (up to 18V), enhancing circuit design versatility.
  • Superior noise margin increases operational accuracy and integrity.
  • Compatible with various logic families, ensuring easy integration.

Applications

  • Digital frequency multipliers and modulators.
  • Error checking and parity generation circuits.
  • Data encryption and security systems.
  • Control systems and automation projects.

This quad XOR gate IC is perfect for projects that demand precise logic operations and low power consumption.
