CSD16340Q3 Real Image CSD16340Q3 real image3102
Same model may have multiple batches, images only for reference.
CSD16340Q3 Real Image CSD16340Q3 real image3102
CSD16340Q3 Real Image CSD16340Q3 real image3102
Same model may have multiple batches, images only for reference.

CSD16340Q3

Part No CSD16340Q3
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 25V 60A 8SON
Datasheet
CSD16340Q3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 21A (Ta), 60A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 8V
Gate-Source Threshold Voltage 1.1V @ 250μA
Max Gate Charge 9.2nC @ 4.5V
Max Input Capacitance 1350pF @ 12.5V
Maximum Gate-Source Voltage +10V, -8V
Power Dissipation (Max) 3W (Ta)
Maximum Rds On at Id,Vgs 4.5 mOhm @ 20A, 8V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (3.3x3.3)
Dimension 8-PowerTDFN
Win Source Part Number 013348-CSD16340Q3
Family Name CSD16340Q3
Introduction Date December 01, 2009
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian CSD16340Q3 CAD Model

Description

Overview

The CSD16340Q3 is an advanced N-channel MOSFET designed for modern electronic applications. Its compact 3x3mm package makes it ideal for applications demanding minimal board space.

Features and Benefits

  • Excellent On-State Resistance: Lowers energy consumption and enhances battery life.
  • High Speed Switching: Increases system efficiency by reducing losses.
  • Robust Construction: Ensures stability and longevity in critical applications.

Applications

  • Consumer Electronics
  • Wireless Charging Stations
  • Power Distribution Units (PDUs)

Additional Details

The CSD16340Q3's high performance and compact design make it a suitable choice for applications requiring efficient power management and reliability.
