CSD17304Q3 Real Image CSD17304Q3 real image3105 CSD17304Q3 Real Image1 CSD17304Q3 Real Image2
Same model may have multiple batches, images only for reference.
CSD17304Q3 Real Image CSD17304Q3 real image3105 CSD17304Q3 Real Image1 CSD17304Q3 Real Image2
CSD17304Q3 Real Image CSD17304Q3 real image3105 CSD17304Q3 Real Image1 CSD17304Q3 Real Image2
Same model may have multiple batches, images only for reference.

CSD17304Q3

Part No CSD17304Q3
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 56A 8SON
Datasheet
CSD17304Q3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 15A (Ta), 56A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 3V, 8V
Gate-Source Threshold Voltage 1.8V @ 250μA
Max Gate Charge 6.6nC @ 4.5V
Max Input Capacitance 955pF @ 15V
Maximum Gate-Source Voltage +10V, -8V
Power Dissipation (Max) 2.7W (Ta)
Maximum Rds On at Id,Vgs 7.5 mOhm @ 17A, 8V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (3.3x3.3)
Dimension 8-PowerTDFN
Win Source Part Number 013361-CSD17304Q3
Family Name CSD17304Q3
Introduction Date February 01, 2010
ECCN EAR99
Halogen Free Not Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian CSD17304Q3 CAD Model

Description

CSD17304Q3 MOSFET

The CSD17304Q3 MOSFET provides a cost-effective solution for simple and complex designs requiring efficient performance in a compact package. It is suitable for both industrial and consumer electronics projects.

  • Applications: Portable electronics, Consumer electronic devices, Industrial power supplies

Features & Benefits

  • Compact QFN package for minimal footprint
  • Lower conduction losses for enhanced energy efficiency
  • Wide range of operations suited for various voltages

This device is ideal for engineers looking to optimize space and efficiency in their projects.
