CSD17310Q5A Real Image CSD17310Q5A Real Image
Same model may have multiple batches, images only for reference.
CSD17310Q5A Real Image CSD17310Q5A Real Image
CSD17310Q5A Real Image CSD17310Q5A Real Image
Same model may have multiple batches, images only for reference.

CSD17310Q5A

Part No CSD17310Q5A
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 100A 8SON
Datasheet
CSD17310Q5A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 21A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 3V, 8V
Gate-Source Threshold Voltage 1.8V @ 250μA
Max Gate Charge 11.6nC @ 4.5V
Max Input Capacitance 1560pF @ 15V
Maximum Gate-Source Voltage +10V, -8V
Power Dissipation (Max) 3.1W (Ta)
Maximum Rds On at Id,Vgs 5.1 mOhm @ 20A, 8V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (5x6)
Dimension 8-PowerTDFN
Win Source Part Number 083177-CSD17310Q5A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian CSD17310Q5A CAD Model

Description

CSD17310Q5A Description

The CSD17310Q5A brings advanced MOSFET technology into play, maximizing efficiency for extensive power handling capabilities. Its SON 5x6 package provides the physical resilience required for demanding tasks.

Features and Benefits

  • Extremely low R<sub>DS(on) for reduced heat dissipation
  • Enhanced thermal performance
  • Optimized for high-frequency and high-efficiency applications
  • Adheres to RoHS and lead-free requirements

Applications

  • High-density switching converters
  • Server power supplies
  • Energy-efficient computing
  • Electric vehicle systems

The CSD17310Q5A is a powerful addition to any toolbox aimed at efficient and reliable high-power switching applications.
